Nine head Twelve station stator coil winding machine
This machine adopts a 9-head 12-station structure, specially designed for geared motors, widely used in household fans, industrial fans and other fields. It can arrange coils accurately and orderly in wire-hanging cup fixtures, with better adaptability for stators with high slot fill factor and small slot openings, and superior forming effect to traditional models.
Integrating automatic segment jumping, wire cutting and indexing in one process without manual intervention, it ensures efficient and consistent winding, greatly reducing operation errors and reject rates.
Equipped with an intelligent fault detection and alarm system, it provides real-time abnormality feedback, clear fault location and convenient maintenance, effectively shortening downtime and ensuring continuous and stable production. The human-machine interface is intuitive, parameters are easy to set, and winding tension can be precisely adjusted as needed. It supports single-step debugging and continuous mass production, flexibly meeting various production scenarios.
The machine features neat winding and excellent coil inserting effect, improving stator winding quality and assembly efficiency. The 12-station collaborative operation greatly increases productivity while ensuring winding accuracy. With high automation, stable and reliable performance and easy maintenance, it is an ideal automatic equipment for high-end stator winding processing.
Features
- 1. Adopting a Nine head Twelve station structure, it suits stators with high slot fill factor and small slot openings. It automatically completes segment jumping, wire cutting and indexing, with neat winding and excellent coil inserting effect.
- 2. Equipped with an intelligent fault detection and alarm system, it provides real-time abnormality alerts, easy maintenance, stable and reliable operation for long-term continuous production.
- 3. Featuring user-friendly HMI, adjustable tension and support for single-step & continuous modes, it is highly automatic and effectively improves production efficiency and product consistency.
